STL130N6F7 N-Channel MOSFET 60V 130A PowerFlat Package
- Brand: STMicroelectronics
- Product Code: STL130N6F7
- Availability: In Stock
$0.25
- Ex Tax: $0.25
Next-Generation Power Efficiency with STM STL130N6F7 MOSFET
STMicroelectronics continues to set industry benchmarks with its STL130N6F7 N-Channel MOSFET, a high-performance power transistor designed for demanding applications requiring exceptional current handling and thermal stability. This 60V, 130A PowerFlat™ device combines advanced STripFET™ F7 technology with a compact surface-mount package, delivering optimal power density for modern electronic systems.
Key Technical Advantages
Engineered for high-efficiency power conversion, the STL130N6F7 demonstrates remarkable electrical characteristics. Its 3.5mΩ maximum on-resistance at 10V gate-source voltage ensures minimal conduction losses, while the 42nC gate charge rating enables fast switching performance. The device's 4V gate threshold voltage maintains reliable operation across varying temperature ranges, and its ±20V gate-source voltage tolerance provides enhanced robustness in industrial environments.
| Parameter | Value |
|---|---|
| Max Drain-Source Voltage | 60V |
| Continuous Drain Current | 130A |
| On-Resistance (Max) | 3.5mΩ |
| Operating Temperature | -55°C to 175°C |
Advanced Thermal Management
The PowerFlat™ 5x6 package design significantly enhances thermal dissipation capabilities. With a maximum power dissipation of 125W in controlled conditions, this MOSFET maintains stable operation even under full load. The 2600pF input capacitance at 25V drain-source voltage allows efficient parallel operation for high-current applications, while the surface-mount packaging simplifies automated assembly processes.
Designed for harsh operating environments, the STL130N6F7's specifications include a 10V gate drive optimization and robust short-circuit protection characteristics. Its automotive-grade temperature rating (-55°C to 175°C) makes it ideal for under-hood vehicle applications, industrial motor controls, and high-current power supplies.
Optimized for Modern Electronics
This STMicroelectronics MOSFET excels in applications requiring high-frequency switching and minimal energy loss. Its 25V @ 2600pF input capacitance specification enables efficient paralleling for power-intensive designs, while the tape-and-reel packaging supports automated manufacturing workflows. The device's 4.8W maximum power dissipation in ambient conditions allows flexible implementation in space-constrained PCB layouts.
As a member of the STripFET™ F7 series, this transistor incorporates advanced trench gate technology for superior on-state resistance and switching performance. Its 250µA gate threshold current ensures compatibility with standard logic-level drivers while maintaining noise immunity in electrically noisy environments.
Design Flexibility Across Industries
From renewable energy systems to automotive battery management, the STL130N6F7 offers unmatched versatility. Its 8-PowerVDFN package provides excellent thermal performance for DC-DC converters, motor controllers, and high-efficiency power supplies. Designers benefit from its compatibility with standard PCB assembly processes while achieving higher current density compared to traditional TO-220 packaged devices.
