STMicroelectronics VN750SMPTR-E N-Channel Power Driver IC - 8-SOIC Package

STMicroelectronics VN750SMPTR-E: High-Performance N-Channel Power Driver for Modern Electronics

The

STMicroelectronics VN750SMPTR-E

is a cutting-edge N-channel power driver IC designed to deliver exceptional performance in industrial automation, automotive systems, and high-precision electronics. Part of the renowned VIPower™ series, this 8-SOIC packaged device combines advanced power management with robust protection features, making it ideal for applications requiring reliable load switching and fault tolerance.

Engineered for efficiency, the VN750SMPTR-E operates seamlessly across a wide voltage range of 5.5V to 36V, supporting high-side output configurations with a maximum output current of 6A. Its ultra-low Rds(on) of 55mΩ ensures minimal power loss, while integrated protection mechanisms like over-temperature shutdown, current limiting, and open-load detection enhance system reliability. This makes it a versatile choice for demanding environments such as motor controls, solenoid drivers, and industrial IoT devices.

Key Technical Advantages

At its core, the VN750SMPTR-E leverages STMicroelectronics' proprietary VIPower technology to optimize thermal performance and energy efficiency. The non-inverting input interface simplifies integration with microcontrollers, while the auto-restart and status flag features enable real-time diagnostics and fault recovery. With an operating temperature range of -40°C to 150°C (TJ), this IC maintains stability in extreme conditions, ensuring uninterrupted operation in automotive and industrial applications.

Technical Specifications & Applications

Parameter	Value
Output Configuration	High Side
Max Output Current	6A
Rds(on)	55mΩ (Max)
Protection Features	Current Limiting, Over Temperature, Over Voltage, Open Load Detect
Mounting Type	Surface Mount

The VN750SMPTR-E's compact 8-SOIC package (3.90mm width) saves board space while maintaining high thermal dissipation. Its compatibility with tape & reel packaging streamlines automated assembly processes, reducing manufacturing costs. This IC excels in applications like programmable logic controllers (PLCs), smart relays, and battery-powered systems where space and energy efficiency are critical.

Why Choose the VN750SMPTR-E?

STMicroelectronics' commitment to quality shines through this device's design. The combination of automotive-grade reliability, advanced fault diagnostics, and ease of integration sets it apart from conventional power drivers. Engineers benefit from reduced design complexity thanks to its built-in protection circuits, which eliminate the need for external components in most use cases. Additionally, its surface-mount packaging aligns with modern PCB assembly standards, ensuring scalability for mass production.
