STMicroelectronics VN750PTTR-E - High-Performance N-Channel Power Driver IC
- Brand: STMicroelectronics
- Product Code: VN750PTTR-E
- Availability: In Stock
$1.10
- Ex Tax: $1.10
STMicroelectronics VN750PTTR-E: High-Performance N-Channel Power Driver for Modern Applications
The STMicroelectronics VN750PTTR-E is a cutting-edge N-channel power driver IC designed to meet the demands of automotive and industrial applications requiring reliable high-side switching solutions. Part of the renowned VIPower™ family, this device combines robust performance with advanced protection features, making it an ideal choice for engineers seeking efficiency and durability in compact electronic systems.
At its core, the VN750PTTR-E operates as a general-purpose power driver with a 1:1 input-to-output ratio, delivering a maximum output current of 6A through its high-side N-channel configuration. This IC eliminates the need for external supply voltage (Vcc/Vdd), simplifying circuit design while maintaining exceptional load-driving capabilities across a wide voltage range of 5.5V to 36V. Its 60mOhm (max) Rds On ensures minimal power loss, enhancing thermal efficiency in demanding environments.
Advanced Protection and Intelligent Features
Engineered for reliability, the VN750PTTR-E integrates comprehensive fault protection mechanisms. Built-in safeguards include fixed current limiting, open load detection, over-temperature shutdown, and over-voltage protection. These features work in tandem to prevent damage from electrical overstress, while the auto-restart function automatically resumes operation after fault conditions clear. A dedicated status flag provides real-time feedback on the device's operational state, enabling proactive system diagnostics.
| Parameter | Value |
|---|---|
| Output Current (Max) | 6A |
| Rds On (Typ) | 60mOhm (Max) |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Package | PPAK / TO-252-5 |
Optimized for Industrial and Automotive Systems
Housed in a surface-mount PPAK package (TO-252-5/DPak), the VN750PTTR-E offers excellent thermal dissipation for high-power applications. Its automotive-grade temperature tolerance (-40°C to 150°C) ensures stable performance in extreme conditions, from engine control units to electric vehicle subsystems. The non-inverting input interface simplifies control logic integration, while the on/off switch configuration provides straightforward operation without complex programming requirements.
As part of STMicroelectronics' VIPower™ series, this IC exemplifies the company's commitment to smart power solutions. The device's tape-and-reel packaging format (TR) facilitates automated assembly processes, making it suitable for high-volume manufacturing in industrial automation, smart grid systems, and next-generation automotive electronics. Whether used in motor control, lighting systems, or power management modules, the VN750PTTR-E delivers consistent performance with minimal design overhead.
Technical Excellence in Power Management
The VN750PTTR-E's design philosophy emphasizes simplicity and robustness. By combining a high-current N-channel MOSFET with integrated protection circuits, STMicroelectronics has created a solution that reduces component count while maintaining exceptional reliability. Its ability to operate without external bootstrap components streamlines PCB layout, and the built-in thermal shutdown protects against overheating in enclosed environments. This combination of features makes it particularly well-suited for applications where space constraints and thermal management are critical design considerations.
Tags: Power Driver IC, N-Channel MOSFET, Automotive Electronics, Industrial Control, Surface Mount IC
