STMicroelectronics VN5025AJTR-E Single High-Side N-Channel Power Driver
- Brand: STMicroelectronics
- Product Code: VN5025AJTR-E
- Availability: In Stock
$1.20
- Ex Tax: $1.20
STMicroelectronics VN5025AJTR-E: Advanced Power Management Solution
Engineered for precision and reliability, the STMicroelectronics VN5025AJTR-E represents the cutting edge of power driver technology. As part of the renowned VIPower™ series, this single-channel N-channel high-side power driver combines robust performance with intelligent protection features, making it ideal for demanding automotive and industrial applications.
Key Features and Technical Excellence
Operating within a wide 4.5V to 36V load voltage range, the VN5025AJTR-E delivers exceptional 28A maximum output current capability with an ultra-low 25mΩ typical Rds(on) value. Its advanced PowerSSO-12™ packaging ensures efficient thermal management while maintaining a compact 3.90mm width profile. The device's non-inverting input configuration and on/off interface simplify integration into modern control systems, while its active status ensures compatibility with next-generation designs.
Engineers will appreciate the comprehensive protection suite including fixed current limiting, over-temperature safeguards, and over-voltage protection. These features work in concert to maintain system integrity across extreme operating conditions, from the frigid -40°C automotive environments to high-temperature industrial installations reaching 150°C junction temperatures.
| Parameter | Specification |
|---|---|
| Output Configuration | High Side |
| Mounting Type | Surface Mount |
| Package | 12-PowerLSOP |
| Protection Features | Current, Thermal, Overvoltage |
Application Versatility
The VN5025AJTR-E's universal design philosophy makes it suitable for diverse applications including automotive relay replacement systems, industrial motor controls, and smart power distribution units. Its tape & reel packaging format supports automated assembly processes, while the non-inverting input architecture enables seamless integration with standard microcontroller outputs.
STMicroelectronics' proprietary manufacturing processes ensure consistent performance across production batches, while the device's 1:1 input/output ratio maintains precise control accuracy. The absence of required Vcc/Vdd supply voltage simplifies power architecture design, reducing overall system complexity and component count.
Design Advantages
When compared to traditional discrete solutions, the VN5025AJTR-E offers significant advantages in both space savings and reliability. The integrated PowerSSO-12™ package reduces PCB footprint requirements by up to 40% while improving thermal dissipation efficiency. Designers benefit from simplified BOM management through its single-component implementation approach, which also enhances system reliability through reduced interconnect points.
