STMicroelectronics STTH15L06FP High Voltage Diode
- Brand: STMicroelectronics
- Product Code: STTH15L06FP
- Availability: In Stock
$0.75
- Ex Tax: $0.75
STTH15L06FP: High-Performance Standard Diode for Demanding Power Applications
STMicroelectronics continues to lead the market with its STTH15L06FP standard diode, a robust solution engineered for high-voltage rectification in industrial and commercial power systems. This TO-220FPAC packaged device combines exceptional electrical characteristics with reliable thermal management, making it an ideal choice for engineers seeking stable performance in demanding operating environments.
Technical Excellence in Power Electronics
Designed to handle extreme electrical loads, the STTH15L06FP delivers 15A average rectified current with a maximum forward voltage drop of just 1.55V at full load. Its 600V maximum reverse voltage rating ensures compatibility with high-power switching circuits, while the 85ns reverse recovery time positions it among the fastest standard diodes in its class. These specifications make it particularly suitable for applications requiring efficient energy conversion with minimal switching losses.
The device's 15µA reverse leakage current at maximum voltage demonstrates its superior insulation properties, maintaining circuit integrity even under thermal stress. With an operating junction temperature rating up to 175°C, this diode can withstand harsh thermal environments without compromising performance longevity.
| Parameter | Value |
|---|---|
| Max Reverse Voltage | 600V |
| Average Rectified Current | 15A |
| Forward Voltage | 1.55V @ 15A |
| Reverse Recovery Time | 85ns |
Industrial-Grade Design for Reliability
Featuring a TO-220-2 full-pack isolated tab package, the STTH15L06FP combines mechanical durability with efficient heat dissipation characteristics. The through-hole mounting configuration ensures stable PCB integration, while the isolated tab design simplifies thermal management in high-power applications. This packaging approach maintains electrical isolation while enabling effective heat transfer to external heatsinks.
As part of STMicroelectronics' active product portfolio, this diode benefits from the manufacturer's ongoing commitment to quality and innovation. The device meets rigorous industry standards for reliability and performance, making it suitable for critical applications in motor drives, power supplies, and industrial automation systems.
Optimized for Modern Power Systems
The STTH15L06FP's fast recovery characteristics (<= 500ns) make it particularly valuable in switched-mode power supplies and motor control circuits where minimizing switching losses is crucial. Its combination of high current capability and fast switching performance enables designers to create more efficient power conversion systems while maintaining component reliability.
Available in tube packaging for convenient handling and assembly, this diode represents excellent value for applications requiring proven performance in a compact form factor. STMicroelectronics' manufacturing expertise ensures consistent quality and long-term supply stability for production environments.
Tags: Power Electronics, Rectifier Diode, High Voltage Diode, Industrial Components, Power Management
