STPS360AF 60V 3A Schottky Diode | Surface Mount SOD128
- Brand: STMicroelectronics
- Product Code: STPS360AF
- Availability: In Stock
$0.09
- Ex Tax: $0.09
Introducing the STPS360AF: High-Performance Schottky Diode for Demanding Applications
STMicroelectronics continues to redefine power semiconductor technology with its STPS360AF Schottky diode – a compact yet powerful solution engineered for modern electronic systems requiring efficient rectification and minimal power loss. This 60V 3A device combines advanced silicon technology with the SOD128Flat surface mount package to deliver exceptional thermal performance in space-constrained designs.
Technical Excellence in Power Management
At the heart of the STPS360AF's capabilities lies its optimized junction design that achieves an impressively low forward voltage drop of 610mV at 3A. This translates to significant conduction loss reduction compared to conventional diodes, making it ideal for power supply and converter applications where efficiency matters. The device's fast recovery characteristics (<500ns) ensure minimal switching losses, while maintaining robustness against leakage currents with just 150µA at maximum reverse voltage.
Engineered for industrial environments, this Schottky diode operates reliably across extreme temperatures (-40°C to 175°C), surpassing standard automotive and industrial requirements. Its SOD-128 package provides excellent thermal dissipation through optimized pad layout, while maintaining compatibility with automated PCB assembly processes.
| Parameter | Value |
|---|---|
| Max Repetitive Reverse Voltage | 60V |
| Forward Current | 3A |
| Forward Voltage | 0.61V @ 3A |
| Reverse Leakage | 150µA @ 60V |
| Package Type | SOD128Flat |
Design Flexibility Across Applications
The STPS360AF's versatility shines in multiple applications including DC-DC converters, power supplies, freewheeling circuits, and reverse battery protection systems. Its surface mount design enables compact PCB layouts while maintaining high current capabilities, making it particularly suitable for:
• Automotive electronics (ECUs, lighting systems)
• Industrial power supplies
• Consumer electronics power management
• Renewable energy systems (solar inverters)
• Motor drive applications
Manufacturing & Sustainability Advantages
Designed for modern production environments, the SOD128Flat package features a low-profile (1.7mm height) and thermal enhanced pad layout that simplifies automated placement and reflow soldering. The RoHS-compliant device meets environmental regulations while maintaining mechanical durability through its molded plastic package.
With tape & reel packaging (TR) for bulk production use, the STPS360AF offers seamless integration into high-volume manufacturing workflows. The device's active status ensures long-term availability for sustained production runs.
Tags: Surface Mount Diode, Fast Recovery Diode, Power Electronics, SOD128 Package, Industrial Diode
